Description:
1.Application:
ADT Series Digital Display Horizontal Torsional Spring Tester is an intellectualization and multiple
function measuring instrument which is designed for testing various kinds of torsion spring.
It can be used in torsion testing system of various shapes of torsion spring, volute spring and
other elastic torsion element. It has the advantages of simple operation, high precision, whole
function and portable.
Widely use in various kinds of electrical, light industry, machinery manufacturing, scientific
research institution and other industries.
2.Technical Parameter:
Model | Biggest Test Torque | Measurement Range | Min. Read Values |
ADT-500A | 500 mN·m | 5~500 (mN·m) | 0.01 mN·m |
ADT-1000A | 1000 mN·m | 10~1000 (mN·m) | 0.1 mN·m |
ADT-2000A | 2000 mN·m | 20~2000 (mN·m) | 0.1 mN·m |
ADT-5000A | 5000 mN·m | 50~5000 (mN·m) | 0.1 mN·m |
Model | Biggest Test Torque | Measurement Range | Min. Read Values |
ADT-1 | 1 N·m | 0.01~1 (N·m) | 0.0001 N·m |
ADT-2 | 2 N·m | 0.02~2 (N·m) | 0.0001 N·m |
ADT-5 | 5 N·m | 0.05~5 (N·m) | 0.0001 N·m |
ADT-10 | 10 N·m | 0.1~10 (N·m) | 0.001 N·m |
ADT-20 | 20 N·m | 0.2~20 (N·m) | 0.001 N·m |
ADT-30 | 30 N·m | 0.3~30 (N·m) | 0.001 N·m |
ADT-50 | 50 N·m | 0.5~50 (N·m) | 0.001 N·m |
Angle Resolution: 0.1°
Measurement Angel Range: 0~ ±9999.9°
Precision: ±1%
Sample Tactical Diameter: 100 mm
The Length Of Specimen: 150 mm
Loading Mode: Manual Loading
Supply Power: 1-Phase, AC 220V, 50Hz
