Description:
1.Application:
SDEKON DGZ-Y Series Digital Elevator Wire Rope Tension Meter is mainly used in elevator wire rope tension test.
To check and adjust each wire rope of elevator in the process of installation, check before acceptance and annual
inspection to ensure its tension as consistent as possible, thereby prolonging the service life of the traction wheel.
The tension tester can also be applied to the bridge with sling, tower wiring, overhead wire, index wire rope and
other tension test.
2.Technical Parameter:
Model | DGZ-Y-3000 | DGZ-Y-5000 |
Diameter | Φ6 mm | Φ8 mm | Φ10 mm | Φ11 mm | Φ13 mm | Φ16 mm |
Range | 3000 N | 5000 N |
Min.Load Division Value | 1 N |
Scientific Measuring Range | 10%~90% |
Accuracy | ≦±5% |
Power | 7.2V, 1.2Vx6 NI-H Battery |
Charger | Input: AC 100~240V; Output: DC 12V 500mA |
