Description:
1.Application:
HB-62.5MDX Automatic Turret Touch Screen Digital Display Brinell Hardness Tester uses the electronic
electric loading, high precision sensor, has unique closed loop control system.
Automatic correction for each test force.
With automatic turret structure, the indenter and objective can switch automatically.
Automatic positioning accuracy of the test point, automatic loading and automatic unloading.
With two objectives lens outer lighting measure, almost solved the problem of cannot measure when
the indentation is too small or too large, brinell outer lighting make the indentation more clear and
measure more precise.
With digital encoder eyepiece structure, measure the D1 and D2 values, hardness value and D1, D2
value will be showed on the screen directly.
The hardness values of rockwell and vickers can be converted.
All data is saved in the U disk in EXCEL format.
2.Technical Parameter:
Model | HB-62.5MDX |
Brinell Hardness Scale | HBW1/1; HBW1/2.5; HBW1/5; HBW2.5/6.25; HBW1/10; HBW2.5/15.625; HBW5/25; HBW1/30; HBW2.5/31.25; HBW2.5/62.5; HBW5/62.5 |
Test Force | 1Kgf(9.8N); 2.5Kgf(24.5N); 5Kgf(49N); 6.25Kgf(61.29N); 10Kgf(98N); 15.625Kgf(153.23N); 25Kgf(245.2N); 30Kgf(294N); 31.25Kgf(306.47N); 62.5Kgf(612.94N) |
Min. Measure Unit | 0.1 um |
Hardness Value Resolution | 0.1 HBW |
Dwell Time | 0~99 s |
Max. Height Of Sample | 180 mm |
Distance From Indenter To The Wall | 160 mm |
Test Microscope Magnification | 50X, 100X |
